Robust Design 8.5-9 GHz 15dBm Rf Amplifier 25 DB High Gain Stability Excellent Linearity

Brand Name : ZR Hi-Tech

Model Number : LT-PA-085090-G25P15

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T

Delivery Time : 4 weeks

Packaging Details : carton packing

Product name : LT-PA series Power Amplifier

Application : Wireless Communication

Flatness : ±1.0dB

Extended Temperature Range : -40~85℃

Frequency range : 8.5 to 9 GHz

Signal Gain : 55dB

Contact Now

​​8.5-9GHz LT-PA Series High-Gain Power Amplifier​​

​​Key Features:​​

  • ​​X-Band Precision Operation (8.5-9GHz)​​
  • ​​55dB High Signal Gain with ±1.0dB Flatness​​
  • ​​15dBm Output Power​​
  • ​​Military-Grade Aluminum Housing​​
  • ​​Extended Temperature Range (-40°C to +85°C)​​
  • ​​Frequency Customization Available​​
  • ​​CE/RoHS/REACH Compliant​​
  • ​​12-Month Manufacturer Warranty​​

​​Product Overview:​​
The ​​ZR LT-PA-085090-G25P15​​ is a high-performance RF power amplifier delivering ​​55dB exceptional gain​​ with ​​±1.0dB outstanding flatness​​ across the ​​8.5-9GHz X-band​​ frequency range. This precision amplifier provides ​​15dBm output power​​ from just ​​5dBm input​​, making it ideal for sensitive radar and satellite communication systems.

Specifications:

Electrical / Optical Characteristics (Ta=25℃±3℃)

Items Specification Conditions
Part Number LT-PA-085090-G25P15
Configuration Module with Connector
Frequency Range 8.5 to 9 GHz
Small Signal Gain 25 dB
Gain Flatness ±1.0 dB
Output Power 15 dBm
Input Power 5 dBm
VSWR 1.9:1
Power Supply +5V / 150mA
Operating Temperature -40 to +70 ℃
Dimension 34.4*16.8*8.1 mm
Note: for custom specs, please contact us directly.
